7.5kw Lab Rod(ball) Ball Mill Machine For Crushing Stone
Introduction:
Small ball mill is the key equipment
for crushing materials after crushing.Small ball mills can be
divided into grid type ball mills and overflow type ball mills
according to different ways of discharging ore.The experimental
ball mill produced by our company from Φ0.9×1.12-Φ1.8×2.1, and the
filling amount is 0.2-1.5t each time, which can meet various
experimental needs.
Technical Parameters:
Item |
Value | Unit |
Remarks | | Diameter |
Φ600 |
mm | |
Length |
1200 |
mm | | | Effective Volume |
0.267 |
3 | | | Mill Speed | Rod Mill | Ball Mill |
r/min | | | 31 | 43 | | Feed Size |
15~25 |
mm |
≤10mmBest | | Discharging Size |
0.074~0.5 |
mm | |
Motor | Type | Power | | | | Y132M26 | 5.5kw | | Rod Mill | | Y132M4 | 7.5kw | | Ball Mill |
Throughput |
80~600 |
Kg/h | | | Outline Size |
2983×938×930 |
mm | |
Weight |
2000 |
kg | |
|
Company profile
Y&X Beijing Technology Co.,Ltd. was founded in 2014 and is
based in Beijing, the capital of China. Our company has become a
professional business that combines scientific research, design,
innovation development, product development and manufacturing with
strong technical capabilities. As a family group, the mission from
the beginning was to expand into foreign markets and provide a
one-stop shop for overseas mining companies.
The company specializes in the research and supply of mineral
processing reagents and equipment, including mineral processing
equipment and laboratory mineral processing equipment; production
is widely used in metallurgy, geology, petroleum, coal, chemicals,
building materials, environmental protection, non-ferrous and
non-ferrous ammunition, Research departments have services te as
dressing plants, mineral processing laboratories in colleges and
universities.
Laboratory equipment for mineral processing: mainly include
crushing, grinding, screening, grading, magnetic separation,
flotation, assay, sample preparation, leaching,
analysis-electrolysis, shaking table, chute and other laboratory
equipment and gravity separation equipment.
Our products sell well in Russia, Mongolia, Chile, Australia,
Zimbabwe, Thailand, Laos, Indonesia,Tanzania, Nigeria and other
countries and regions.
The enterprise has passed the IS09001 quality management system
certification, and the product quality conforms to the relevant
technical standards promulgated by the state and the enterprise.
FAQ
1: What's the standard length of your profiles and tube?
A: The standard length of profiles and tube are 5800mm to suit for
small container, and we also can cut to specific length, however a
surcharge of machining and material scrap cost will be charged
accordingly based on each individual invoice.
Q2: What's your MOQ?
A: we have no MOQ for our new customers, however a surcharge of
USD80 will apply for all orders less that USD 1000 for custom
handing cost purpose.
Q3: what is your payment terms?
A: The payment terms we accept is T/T or irrevocable L/C at sight,
T/T preferred.
Q4: What's the lead time for small order and mass production?
A: 1-3 working days for small order, and 3-10 working days for mass
production of material, and the final lead time will be subject to
each individual invoice.
Q5: What certification do you have?
A: We have ISO 9001:2008 certificate.
